Group Size:DIN [BCI]
Capacity:245 Ah
Reserve Capacity:
457 min
120 min
CCA:930 Amps
Electrical Specifications
Nominal Voltage:6V
C100:270 Ah
C20:245 Ah
C10:221 Ah
C5:198 Ah
C3:166 Ah
C2:150 Ah
C1:137 Ah
CCA:930 Amps
CA or MCA:1120 Amps
PHCA: 2000Amps
Internal Resistance:1.4 mΩ
Mechanical Specifications
Group Size: DIN
Terminal Type: AP
Terminal Torque:
4.2 - 5.8 ft/lbs
50 - 70 lbs/in
5.6 - 7.9 Nm
Height (w/ terminal): 10.83" / 275mm
Height (case only): 10.83" / 275mm
Width: 7.48" / 190mm
Length: 9.61" / 244mm
Weight: 71.2lbs / 32.3Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
