Group Size: 4D [BCI]
Capacity:210Ah
Reserve Capacity:
400 min at 25A
105 min at 75A
CCA:1180 Amps
Electrical Specifications
Nominal Voltage:12V
C100:231 Ah
C20:210 Ah
C10:189 Ah
C5:172 Ah
C3:143 Ah
C2:128 Ah
C1:116 Ah
CCA:1180 Amps
CA or MCA:1425 Amps
PHCA: 2000Amps
Internal Resistance:2.3 mΩ
Mechanical Specifications
Group Size: 4D
Terminal Type: APW
Terminal Torque:
4.4 - 5.9 ft/lbs
53 - 71 lbs/in
6 - 8 Nm
Height (w/ terminal): 8.88" / 225mm
Height (case only): 8.43" / 214mm
Width: 8.23" / 209mm
Length: 20.87" / 530mm
Weight: 133.1lbs / 60.5Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
