Group Size: NA [BCI]
Capacity:160Ah
Reserve Capacity:
300 min at 25A
82 min at 75A
CCA:910 Amps
Electrical Specifications
Nominal Voltage:12V
C100:176 Ah
C20:160 Ah
C10:142 Ah
C5:130 Ah
C3:102 Ah
C2:90 Ah
C1:85 Ah
CCA:910 Amps
CA or MCA:1070 Amps
PHCA: 1500Amps
Internal Resistance:2.8 mΩ
Mechanical Specifications
Group Size: NA
Terminal Type: M8
Terminal Torque:
5.2 - 6.7 ft/lbs
62 - 80 lbs/in
7 - 9 Nm
Height (w/ terminal): 9.49" / 241mm
Height (case only): 9.49" / 241mm
Width: 6.73" / 171mm
Length: 19.06" / 484mm
Weight: 100.1lbs / 45.4Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
