Group Size: GC12 [BCI]
Capacity:135Ah
Reserve Capacity:
260 min at 25A
88 min at 56A
60 min at 75A
CCA:900 Amps
Electrical Specifications
Nominal Voltage:12V
C100:155 Ah
C20:135 Ah
C10:127 Ah
C5:117 Ah
C3:96 Ah
C2:94.4 Ah
C1:75 Ah
CCA:900 Amps
CA or MCA:1050 Amps
PHCA: 2000Amps
Internal Resistance:2.3 mΩ
Mechanical Specifications
Group Size: GC12
Terminal Type: M8 + TP08
Terminal Torque:
5.2 - 6.7 ft/lbs
62 - 80 lbs/in
7 - 9 Nm
Height (w/ terminal): 11.57" / 294mm
Height (case only): 10.51" / 267mm
Width: 7.17" / 182mm
Length: 12.87" / 327mm
Weight: 93.92lbs / 42.6Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
