Group Size: DIN [BCI]
Capacity:140Ah
Reserve Capacity:
260 min at 25A
62 min at 75A
CCA:795 Amps
Electrical Specifications
Nominal Voltage:12V
C100:154 Ah
C20:140 Ah
C10:126 Ah
C5:115 Ah
C3:95 Ah
C2:88 Ah
C1:77 Ah
CCA:795 Amps
CA or MCA:950 Amps
PHCA: 1400Amps
Internal Resistance:3.6 mΩ
Mechanical Specifications
Group Size: DIN
Terminal Type: M8 + TP08
Terminal Torque:
5.2 - 6.7 ft/lbs
62 - 80 lbs/in
7 - 9 Nm
Height (w/ terminal): 11.38" / 289mm
Height (case only): 10.39" / 264mm
Width: 6.77" / 172mm
Length: 13.43" / 341mm
Weight: 94.82lbs / 43.1Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
