Group Size: 921 [BCI]
Capacity:215Ah
Reserve Capacity:
420 min at 25A
110 min at 75A
CCA:1000 Amps
Electrical Specifications
Nominal Voltage:12V
C100:240 Ah
C20:215 Ah
C10:193 Ah
C5:172 Ah
C3:152 Ah
C2:132 Ah
C1:112 Ah
CCA:1000 Amps
CA or MCA:1200 Amps
PHCA: 2000Amps
Internal Resistance:2.3 mΩ
Mechanical Specifications
Group Size: 921
Terminal Type: DTW
Terminal Torque:
4.4 - 5.9 ft/lbs
53 - 71 lbs/in
6 - 8 Nm
Height (w/ terminal): 14.65" / 372mm
Height (case only): 13.86" / 352mm
Width: 7.01" / 178mm
Length: 15.0" / 381mm
Weight: 132.3lbs / 60Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
