Group Size:27 [BCI]
Capacity:105 Ah
Reserve Capacity:
175 min at 25A
43 min at 75A
CCA:680 Amps
Electrical Specifications
Nominal Voltage:12V
C100:115 Ah
C20:105 Ah
C10:95 Ah
C5:86 Ah
C3:71 Ah
C2:63 Ah
C1:59 Ah
CCA:680 Amps
CA or MCA:820 Amps
PHCA: 1050Amps
Internal Resistance:4.0 mΩ
Mechanical Specifications
Group Size: 27
Terminal Type: M8 + TP08
Terminal Torque:
5.2 - 6.7 ft/lbs
62 - 80 lbs/in
7 - 9 Nm
Height (w/ terminal): 9.84" / 250mm
Height (case only): 8.31" / 211mm
Width: 6.65" / 169mm
Length: 12.07" / 307mm
Weight: 66.58lbs / 30.2Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
