Group Size:27 [BCI]
Capacity:220 Ah
Reserve Capacity:
425 min
112 min
CCA:990 Amps
Electrical Specifications
Nominal Voltage:6V
C100:242 Ah
C20:220 Ah
C10:198 Ah
C5:180 Ah
C3:149 Ah
C2:134 Ah
C1:125 Ah
CCA:990 Amps
CA or MCA:1170 Amps
Internal Resistance:1.5 mΩ
Mechanical Specifications
Group Size:27
Terminal Type:M8
Terminal Torque:
5.2 - 6.7 ft/lbs
62 - 80 lbs/in
7 - 9 Nm
Height (w/ terminal): 8.9" / 226mm
Height (case only): 8.66" / 220mm
Width: 6.85" / 174mm
Length: 12.05" / 306mm
Weight: 72.09lbs / 32.7Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
