Group Size:L16 [BCI]
Capacity:415 Ah
Reserve Capacity:
885 min
229 min
CCA:1500 Amps
Electrical Specifications
Nominal Voltage:6V
C100:460 Ah
C20:415 Ah
C10:374 Ah
C5:340 Ah
C3:282 Ah
C2:246 Ah
C1:232 Ah
CCA:1500 Amps
CA or MCA:1800 Amps
PHCA: 2000Amps
Internal Resistance:1.6 mΩ
Mechanical Specifications
Group Size: L16
Terminal Type: DTW
Terminal Torque:
4.4 - 5.9 ft/lbs
53 - 71 lbs/in
6 - 8 Nm
Height (w/ terminal): 16.69" / 424mm
Height (case only): 15.9" / 404mm
Width: 7.05" / 179mm
Length: 11.61" / 295mm
Weight: 123.2lbs / 56Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
