Group Size:GC2H [BCI]
Capacity:250 Ah
Reserve Capacity:
531 min
135 min
CCA:960 Amps
Electrical Specifications
Nominal Voltage:6V
C100:275 Ah
C20:250 Ah
C10:229 Ah
C5:204 Ah
C3:169 Ah
C2:157 Ah
C1:136 Ah
CCA:960 Amps
CA or MCA:1160 Amps
PHCA: 2000Amps
Internal Resistance:1.6 mΩ
Mechanical Specifications
Group Size: GC2H
Terminal Type: M8 + TP08
Terminal Torque:
5.2 - 6.7 ft/lbs
62 - 80 lbs/in
7 - 9 Nm
Height (w/ terminal): 11.14" / 283mm
Height (case only): 10.47" / 266mm
Width: 7.13" / 181mm
Length: 10.31" / 262mm
Weight: 76.1lbs / 34.5Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
