Group Size:J305 [BCI]
Capacity:335 Ah
Reserve Capacity:
751 min
184 min
CCA:1300 Amps
Electrical Specifications
Nominal Voltage:6V
C100:370 Ah
C20:335 Ah
C10:300 Ah
C5:274 Ah
C3:222 Ah
C2:204 Ah
C1:184 Ah
CCA:1300 Amps
CA or MCA:1560 Amps
PHCA: 2000Amps
Internal Resistance:1.6 mΩ
Mechanical Specifications
Group Size: J305
Terminal Type: DTW
Terminal Torque:
4.4 - 5.9 ft/lbs
53 - 71 lbs/in
6 - 8 Nm
Height (w/ terminal): 14.37" / 365mm
Height (case only): 13.58" / 345mm
Width: 7" / 178mm
Length: 11.61" / 295mm
Weight: 105.4lbs / 47.8Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
