Group Size:L16 [BCI]
Capacity:1150 Ah
Reserve Capacity:
2235 min
658 min
CCA:4500 Amps
Electrical Specifications
Nominal Voltage:2V
C100:1275 Ah
C20:1150 Ah
C10:1040 Ah
C5:945 Ah
C3:786 Ah
C2:702 Ah
C1:667 Ah
CCA:4500 Amps
CA or MCA:5400 Amps
Internal Resistance:1.6 mΩ
Mechanical Specifications
Group Size:L16
Terminal Type:M10
Terminal Torque:
8.1 - 10.3 ft/lbs
97 - 124 lbs/in
11 - 14 Nm
Height (w/ terminal): 16.18" / 411mm
Height (case only): 15.91" / 404mm
Width: 7.05" / 179mm
Length: 11.61" / 295mm
Weight: 127lbs / 57.6Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
