Group Size:GC8 [BCI]
Capacity:180 Ah
Reserve Capacity:
335 min
125 min
CCA:1000 Amps
Electrical Specifications
Nominal Voltage:8V
C100:198 Ah
C20:180 Ah
C10:165 Ah
C5:148 Ah
C3:136 Ah
C2:126 Ah
C1:102 Ah
CCA:1000 Amps
CA or MCA:1220 Amps
PHCA: 2000Amps
Internal Resistance:2.0 mΩ
Mechanical Specifications
Group Size: GC8
Terminal Type: M8
Terminal Torque:
5.2 - 6.7 ft/lbs
62 - 80 lbs/in
7 - 9 Nm
Height (w/ terminal): 10.71" / 272mm
Height (case only): 10.55" / 268mm
Width: 7.16" / 182mm
Length: 10.24" / 260mm
Weight: 75.4lbs / 34.2Kg
Case Type: ABS Plastic (Flame Resistant - Rating: UL94-HB)
