Series: AGM-S
Volts: 8V
Cells: 4
Terminal Type: F14(M8) and TP08 Adapter [+21mm]
Included Hardware: M8 stainless bolts & washers & TP08 adapter
Size & Thread: M8
Warranty: See Warranty Terms
Design: GC8T
Charge Voltage Range: 2.45 V/cell @ 25°C (77°F)
Float Voltage Range: 2.3 V/cell @ 25°C (77°F)
Recommended Charge Current: 40 A
Maximum Charge Current: 60 A
Self-Discharge Rate: Less than 2% per month at 25°C (77°F)
Internal Resistance: 3 mΩ
Cold Crank Amps (CCA) 0°F / -18°C: 1100
Marine Crank Amps (MCA) 32°F / 0°C: 1380
Reserve Capacity (RC @ 25A): 380 Minutes
Reserve Capacity (RC @ 75A): 100 Minutes
Capacity Affect by Temperature | 40°C (104°F) |
25°C (77°F) |
0°C (32°F) |
-15°C (5°F) |
---|---|---|---|---|
102% | 100% | 85% | 65% |
Hour Rate | Capacity / AMP Hour | Current / AMPs |
---|---|---|
@ 100 Hour Rate | 230 AH | 2.3 A |
@ 20 Hour Rate | 200 AH | 10 A |
@ 10 Hour Rate | 190 AH | 19 A |
@ 5 Hour Rate | 176 AH | 35.2 A |
Cut Off Voltage | Constant Current Discharge | ||||||||
---|---|---|---|---|---|---|---|---|---|
VPC | 30 min | 1 hr | 2 hr | 3 hr | 4 hr | 5 hr | 6 hr | 8 hr | 10 hr |
110.6 | 110.6 | 67.3 | 51.6 | 40.9 | 35.2 | 29 | 23.4 | 19.5 |
Specifications | ||
---|---|---|
Weight | 38 kg | 84 lbs |
Length | 260 mm | 10.24" |
Width | 182 mm | 7.17" |
Height Incl. Term. | 300 mm | 11.81" |
Container | ABS | |
Cover | ABS | |
Handles | Rope / Plastic Handle | |
|
Product measurements & weights are calculated based on sample data. Individual specifications are subject to vary due to the manufacturing process & battery components.
