Series: AGM-S
Volts: 12
Cells: 6
Terminal Type: F12(M8) and TP08 Adapter [+21mm]
Included Hardware: M8 stainless bolts & washers & TP08 adapter
Size & Thread: M8
Warranty: See Warranty Terms
Design: SPEC
Charge Voltage Range: 14.7V @ 25°C (77°F)
Float Voltage Range: 13.8V @ 25°C (77°F)
Recommended Charge Current: 30 A
Maximum Charge Current: 40 A
Self-Discharge Rate: Less than 2% per month at 25°C (77°F)
Internal Resistance: 3.6 mΩ
Cold Crank Amps (CCA) 0°F / -18°C: 795
Marine Crank Amps (MCA) 32°F / 0°C: 950
Reserve Capacity (RC @ 25A): 260 Minutes
Reserve Capacity (RC @ 75A): 75 Minutes
Hour Rate | Capacity / AMP Hour | Current / AMPs |
---|---|---|
@ 100 Hour Rate | 160 AH | 1.6 A |
@ 20 Hour Rate | 145 AH | 7.25 A |
@ 10 Hour Rate | 126 AH | 12.6 A |
@ 5 Hour Rate | 115 AH | 23 A |
Cut Off Voltage | Constant Current Discharge | ||||||
---|---|---|---|---|---|---|---|
1.75 VPC | 1 hr | 2 hr | 3 hr | 4 hr | 5 hr | 8 hr | 10 hr |
76.9 | 44.3 | 31.8 | 22.7 | 15.3 | 12.6 | 10.5 |
Specifications | ||
---|---|---|
Weight | 44 kg | 97 lbs |
Length | 341 mm | 13.43" |
Width | 172 mm | 6.77" |
Height Incl. Term. | 309 mm | 12.17" |
Container | ABS | |
Cover | ABS | |
Handles | Rope / Plastic Handle | |
|
Product measurements & weights are calculated based on sample data. Individual specifications are subject to vary due to the manufacturing process & battery components.
