Frigoboat K50F Keel-Cooled Marine Refrigeration System 12/24V

The Frigoboat K50F is a high-capacity keel-cooled marine refrigeration system designed for larger refrigeration and freezer applications aboard sailboats, powerboats, and offshore cruising yachts. Featuring a keel-mounted heat exchanger, the K50F transfers heat directly into seawater without requiring a pump, providing outstanding cooling performance and energy efficiency.

The system comes pre-charged with refrigerant and utilizes Frigoboat quick-connect fittings for easier installation. It is compatible with a variety of evaporator options, allowing custom refrigerator and freezer configurations tailored to onboard storage requirements.

Key Features

• High-capacity keel-cooled refrigeration system
• Efficient 12V/24V DC operation
• Secop/Danfoss BD50 compressor technology
• No water pump required
• Excellent cooling performance for large refrigerator and freezer compartments
• Pre-charged refrigeration circuit with quick-connect fittings
• Automatic battery protection system
• Compact and durable marine-grade design
• Suitable for offshore and liveaboard vessels
• Compatible with multiple Frigoboat evaporator styles

Technical Specifications

• Voltage: 12/24V DC
• Compressor: Secop/Danfoss BD50
• Cooling Method: Keel Cooler Heat Exchanger
• Refrigerant: R134a
• Application: Marine Refrigeration & Freezer Systems
• Installation: Keel-mounted external heat exchanger
