Frigoboat Capri 35F Air Cooled Compressor 12/24V Marine Refrigeration System

The Frigoboat Capri 35F is a high-efficiency air-cooled marine refrigeration condensing unit designed for compact onboard cooling systems. Built around the Danfoss BD35 compressor platform, it delivers reliable refrigeration performance for small to mid-sized iceboxes while maintaining low power consumption. The integrated forced-air condenser system uses a fan and ducted airflow to efficiently dissipate heat, and can be vented remotely for improved installation flexibility. Equipped with Frigoboat self-sealing refrigerant couplings, it is designed for quick installation and long-term reliability in marine environments.

Specifications

• Model: Capri 35F
• Part Number: E51430
• Compressor Type: Danfoss/Secop BD35F DC compressor
• System Type: Air-cooled condensing unit
• Voltage: 12V / 24V DC automatic operation
• Cooling Capacity:
  • Refrigerator: up to 200 liters
  • Freezer: up to 70 liters
• Installation: Horizontal mounting required
• Cooling Method: Forced-air fan with ducted heat discharge capability
• Refrigerant: R134a (factory pre-charged system)
• Protection: Automatic low-voltage battery protection
• Connections: Frigoboat self-sealing quick-connect fittings

Additional Features

• Forced-air condenser with optional ducted heat exhaust
• Plug-and-play pre-charged refrigerant system
• Low power draw optimized for battery-based marine systems
• Suitable for continuous-duty marine operation
• Compatible with Frigoboat evaporators and thermostat
