Series 30 Ball Bearing Orbit Block™, Double with Becket
Hover over image to zoom
Product Description
Series 30 Ball Bearing Orbit Block™, Double with Becket
Double sheave block with becket and non-swivel shackle head.
FEATURES
Lightweight.
Highest working load in its class.
Secure, versatile attachment.
Ultra low profile thru-sheave becket.
Low friction 2-stage ball bearing system provides consistent performance over the full working load range.
SP versions feature a Nylatron® sheave suitable for both rope and wire.
Specifications
| Max. Rope diameter (in) | 5/16 |
|---|---|
| M.W.L. (lb) | 990* |
| Sheave diameter (in) | 1 3/16 |
| B.L. (lb) | 1980 |
| Weight (oz) | 2 |
| Notes: | Becket suits up to 6mm (1/4ʺ) line. For lines above 6mm (1/4") use an additional Dyneema® link (sold separately). Load on becket not to exceed 25% of block load. Suitable for 4:1 system at rated block load. |
